Custom Gaskets & Inserts
Custom Gaskets & Inserts – Precision Seals to Your Specification
We manufacture bespoke gaskets and inserts from a wide range of rubber,
sponge and foam materials. Whether you need a single prototype or high-volume production,
we provide fast quotes, expert material advice and ISO-certified quality.
How to Order Custom Gaskets
- 1. Send your drawing or sample
Upload CAD, PDF or a physical sample. - 2. Material recommendation
We help choose the right compound for temperature, chemical and sealing needs. - 3. Rapid quotation
Receive your quote within 24 hours (standard jobs). - 4. Production & delivery
Typical lead time 2–5 working days; complex tooling may take longer.
- Strips
- Coils
- Pressed parts
- Custom made gaskets
- Profiled foam
- Laminated parts
- Waterjet cut parts
- Inserts
- Gaskets made to drawing specifcation
- Advice on correct material
- Fast turnaround
- Precision gaskets
- Industrial machinery or hands cutting gaskets
- Over 30 years experience
- Tailored gaskets
Materials
Material Options
- EPDM – excellent weather, ozone and UV resistance
- Neoprene – good oil & chemical resistance
- Nitrile (Buna-N) – outstanding oil/fuel resistance
- Silicone – wide temperature range, food/medical grades available
- Closed-cell sponge & foam – compressible, lightweight sealing
- Cloth-inserted rubber – added strength for heavy duty applications
Not sure which material is right? Contact us for free technical advice.
Technical Capabilities
| Thickness Range | 0.5 mm – 10 mm (material dependent) |
|---|---|
| Cutting Methods | Die-cutting, water-jet, CNC routing, laser |
| Maximum Size | Up to 2 m × 1 m sheets (larger with sectional cuts) |
| Tolerance | ±0.1 mm for thin gauges, ±0.2 mm for thicker sections |
| Minimum Order | 1 prototype or sample piece |
| Lead Time | 2–5 working days typical; rush service available |
| Certifications | ISO 9001 quality management, RoHS compliant materials |
Frequently Asked Questions
What file formats do you accept for drawings?
We accept DXF, DWG, PDF, AI, EPS and most common CAD formats. A clear dimensioned PDF is sufficient for many jobs.
Can you help me choose a material?
Yes. Tell us the operating temperature, environment and chemical exposure and we’ll recommend the best compound for performance and cost.
What are the typical lead times?
Standard jobs ship within 2–5 working days. Prototype or urgent jobs can often be turned around faster—ask about our express service.
Do you offer samples before full production?
Yes. We can provide prototype pieces or sample cuts for fit and function testing before committing to a production run.
What is the minimum order quantity (MOQ)?
No strict MOQ—single pieces or small batches are welcome.
Can you reverse-engineer a gasket from a sample?
Yes. Send us your sample and we can create CAD files and reproduce it accurately.
